Introduction to industrial pipes and scaffolding

"Industrial pipes and scaffolding pipes are widely used in industrial machinery and equipment and some tools and equipment. Proper ductility and wing strength, precision dimensions and good weldability of industrial pipes and scaffolding have increased its use in various industries. Pars Profiles World Group currently manufactures and manufactures the best quality raw materials for domestic and foreign markets. "

Industrial pipes according to DIN 2394 standard

Dimensions
(mm)

Thickness (mm)

  1 1.25 1.40 1.50 1.60 1.75 1.80 2 2.30 2.50 2.60 2.90 3 3.20 3.50 3.60 3.70 3.80 4
10 0.224 0.272 0.300 0.317 0.335 0.360 - - - - - - - - - - - - -
12 0.273 0.335 0.370 0.392 0.415 0.447 0.457 - - - - - - - - - - - -
13 0.298 0.365 0.405 0.430 0.455 0.490 0.502 0.578 0.613 - - - - - - - - - -
13.5 0.312 0.382 0.422 0.448 0.475 0.512 0.252 0.573 0.642 - - - - - - - - - -
14 0.323 0.397 0.440 0.467 0.493 0.533 0.547 0.598 0.670 - - - - - - - - - -
14.5 0.336 0.412 0.457 0.486 0.514 0.555 0.570 0.622 - - - - - - - - - - -
15 0.348 0.428 0.475 0.505 0.533 0.578 0.592 0.648 0.728 - - - - - - - - - -
16 0.373 0.460 0.508 0.542 0.573 0.622 0.637 0.697 0.785 - - - - - - - - - -
17.2 0.4303 0.497 0.552 0.587 0.622 0.673 0.690 0.757 0.853 0.915 - - - - - - - - -
18 0.423 0.522 0.578 0.617 0.653 0.708 0.727 0.797 0.900 0.965 - - - - - - - - -
19 0.448 0.553 0.613 0.653 0.693 0.752 0.772 0.847 0.957 1.027 - - - - - - - - -
19.1 0.451 0.556 0.617 0.658 0.697 0.756 0.776 0.852 0.962 1.034 - - - - - - - - -
20 0.473 0.583 0.647 0.692 0.733 0.795 0.817 0.897 1.013 1.090 - - - - - - - - -
21 0.498 0.615 0.683 0.728 0.733 0.838 0.860 0.947 1.072 1.152 1.192 - - - - - - - -
21.25 0.505 0.623 0.692 0.738 0.783 0.850 0.872 0.958 1.085 1.167 1.208 - - - - - - - -
22 0.523 0.647 0.718 0.767 0.813 0.883 0.905 0.997 1.128 1.215 1.257 - - - - - - - -
22.2 0.528 0.652 0.725 0.773 0.822 0.892 0.915 1.007 1.140 1.227 1.270 - - - - - - - -
22.5 0.535 0.662 0.735 0.783 0.833 0.905 0.928 1.022 1.157 1.245 - - - - - - - - -
23.5 0.560 0.693 0.770 0.822 0.873 0.948 0.973 1.072 1.215 1.307 - - - - - - - - -
24 0.573 0.708 0.788 0.840 0.893 0.970 0.995 1.097 1.243 1.338 - - - - - - - - -
25 0.598 0.740 0.823 0.878 0.933 1.013 1.040 1.145 1.300 1.402 - - - - - - - - -
25.4 0.608 0.752 0.837 0.893 0.948 1.030 1.058 1.165 1.323 1.427 - - - - - - - - -
26 0.623 0.770 0.858 0.915 0.972 1.057 1.085 1.195 1.358 1.463 1.515 1.668 1.718 - - - - - -
26.70 0.640 0.792 0.882 0.942 1.000 0.1087 1.117 1.230 1.398 1.507 1.561 1.719 1.771 - - - - - -
28 0.672 0.833 0.928 0.990 1.052 1.143 1.175 1.295 1.472 1.588 - - - - - - - - -
28.6 0.687 0.852 0.948 1.012 1.077 1.170 1.202 1.325 1.507 1.625 1.683 1.857 1.913 2.025 2.188 - - - -
30 0.722 0.895 0.997 1.065 1.132 1.232 1.265 1.395 1.587 1.712 - - - - - - - - -
31.8 0.767 0.952 1.060 1.132 1.203 1.310 1.345 1.485 1.690 1.825 - - - - - - - - -
32 0.772 0.957 1.067 1.140 1.212 1.318 1.353 1.495 1.702 1.837 - - - - - - - - -
33 0.797 0.988 1.102 1.177 1.252 1.362 1.398 1.545 1.758 1.898 1.968 2.173 2.242 2.375 2.572 2.636 2.700 2.764 2.889
33.4 0.815 1.010 1.127 1.203 1.280 1.393 1.430 1.578 1.798 1.943 2.013 2.225 2.293 2.432 2.633 - - - -
34 0.822 1.020 1.137 1.215 1.292 1.405 1.443 1.593 1.817 1.962 2.033 2.247 2.317 2.455 2.658 2.726 2.792 2.858 2.989
35 0.847 1.050 1.172 1.252 1.332 1.450 1.488 1.643 1.873 2.023 - - - - - - - - -
37 0.897 1.113 1.242 1.327 1.410 1.537 1.578 1.743 1.988 2.148 - - - - - - - - -
38 0.922 1.143 1.277 1.363 1.450 1.580 1.623 1.793 2.045 2.210 2.292 2.535 2.615 2.773 3.007 3.085 3.162 3.237 3.387
38.70 0.938 1.167 1.300 1.390 1.478 1.610 1.655 1.828 2.085 2.253 2.338 2.585 2.667 2.830 0.36 3.147 3.225 3.303 3.457
40 0.972 1.207 1.347 1.438 1.530 1.667 1.713 1.893 2.160 2.335 2.422 2.680 2.765 2.933 0.182 3.263 3.345 3.427 3.587
42 1.022 1.268 1.415 1.513 1.610 1.755 1.802 1.993 2.275 2.460 2.552 2.823 2.913 3.092 3.357 3.443 3.530 3.615 3.785
42.25 1.032 1.282 1.430 1.528 1.627 1.772 1.820 2.012 2.297 2.485 2.577 2.853 2.943 3.125 3.392 3.478 3.567 3.653 3.825
44.75 1.090 1.355 1.512 1.615 1.720 1.875 1.925 2.130 2.432 2.630 2.730 3.023 3.120 3.312 3.597 3.690 3.783 3.875 4.060
45 1.097 1.362 1.520 1.625 1.730 1.885 1.937 2.142 2.447 2.647 2.745 3.042 3.138 3.332 3.618 3.712 3.807 3.900 4.085
46.7 1.138 1.415 1.580 1.688 1.797 1.960 2.013 2.227 2.543 2.752 2.855 3.163 3.265 3.467 3.767 3.865 3.963 4.060 4.253
47 1.145 1.425 1.590 1.700 1.810 1.972 2.027 2.242 2.560 2.772 2.875 3.185 3.288 3.492 3.792 3.892 3.990 4.088 4.283
48 1.170 1.455 1.625 1.737 1.848 2.017 2.072 2.292 2.618 2.833 2.940 3.258 3.362 3.570 3.880 3.982 4.082 4.183 4.383
48.6 1.185 1.473 1.645 1.760 1.873 2.042 2.098 2.322 2.652 2.870 2.978 3.302 3.407 3.618 3.932 4.035 4.138 4.240 4.443
50 1.220 1.518 1.695 1.812 1.928 2.103 2.162 2.392 2.733 2.958 3.070 3.402 3.512 3.730 4.053 4.160 4.267 4.373 4.583
50.8 1.240 1.543 1.723 1.842 1.960 2.138 2.197 2.433 2.778 3.007 3.122 3.460 3.572 3.793 4.123 4.232 4.340 4.448 4.663
51 1.245 1.548 1.730 1.850 1.968 2.147 2.205 2.442 2.790 3.020 3.135 3.475 3.587 3.810 4.140 4.250 4.358 4.467 4.682
54 1.320 1.642 1.833 1.962 2.088 2.277 2.340 2.590 2.962 3.207 3.328 3.692 3.810 4.048 4.402 4.518 4.635 4.752 4.982
55 - 1.673 1.868 1.998 2.128 2.322 2.385 2.640 3.018 3.268 3.393 3.763 3.885 4.128 4.490 4.608 4.728 4.845 5.082
55.56 1.358 1.692 1.888 2.020 2.150 2.345 2.410 2.668 3.052 3.303 3.430 3.803 3.927 4.173 4.538 4.658 4.778 4.898 5.138
57 1.395 1.735 1.938 2.073 2.208 2.408 2.475 2.740 3.133 3.393 3.523 3.908 4.035 4.288 4.663 4.788 4.912 5.035 5.280

Properties of scaffolding pipes

No fluid movement in it

Lack of fluid transfer in industrial and scaffold pipes

Failure to perform a series of tests

Failure to perform a series of tests and technical analyzes such as hydrostatic (no leakage) on it

Capability of different weights

Capability of different weights in industrial and scaffold pipes

High strength and toughness

High strength and bending and torsion resistance

عمران و ساختمان سازی

Applications

Industrial and scaffolding pipes in different fields

  • Home Appliances and Kitchen Industries

  • Heavy and light cars room

  • Agricultural and Food Industries

  • Health & Medical Supplies

  • Transmission of water, gas, electricity and fluids

  • sport-icon

    Sport and recreation supplies

Other uses of pipe profiles are in the manufacture of metal tables and chairs, writing desks and benches, laboratory equipment and signage, driving and advertising boards.
